PLANETARY MIXER
PLANETARY MIXER
Table of Contents
The Planetary Mixer is an efficient m ixer and the planetary motion of various beater enables faster mixing of material in lesser time. It is built in strong body to ensure low vibrations and smooth functioning. Hydraulic vertical movement of both the bowl and the top agitator for easy operation.
Features
– PlanetaryMixeris ideal formixingofwet/dry materials.
– Slow speed is used for dry mixing with less dust generation and fasterspeed for kneading operation during wet granulation.
– The mixing bowl can be jacketed for electric / steam heating.
– Manual lifting arrangements for agitators upt050Ltsand hydraulic lifting arrangement forcapacities of 100 Its and above.
– The top of the mixing bowl has an S.S. lid with a charging hole
– The mixing bowl is provided with castor wheels and locking system for easy handling and transportation.
| Model | Gross Capacity(L) | Working Capacity | Hydraulic Lifting Motor | Main Motor |
| ST/OMP/IOO | 50 | 40 | Manual | 1 HP |
| ST/OMP/200 | 100 | 80 | 0.5 HP | 3 HP |
| ST/OMP/300 | 200 | 150 | 1 HP | 5 HP |
| ST/OMP/500 | 300 | 250 | 1 HP | 7.5 HP |
| ST/OMP/IOOO | 600 | 450 | 1.5 HP | 15 HP |
| ST/OMP/2000 | 800 | 650 | 1.5 HP | 15 HP |
| ST/OMP/3000 | 1000 | 800 | 2 HP | 20 HP |
| ST/OMP/5000 | 1200 | 1000 | 2 HP | 25 HP |
We deliver our products nationwide, including key industrial hubs like Ankleshwar, Ahmedabad, Mumbai, and Delhi. After order confirmation, expect delivery within 4-6 weeks, depending on customization. Reach out for a detailed timeline.
